2. Safety Instructions
Warning
ELECTRIC SHOCK HAZARD
Please read this manual carefully before the product is installed and put into use.
This product is designed and tested in accordance with international standards. The equipment should be used for the designated application only.
Refer to the specifications provided by the manufacturer of the battery to ensure that the battery is suitable for use with this product. The battery manufacturer's safety instructions should always be observed.
Protect the solar modules from incident light during installation, e.g. cover them.
Never touch uninsulated cable ends.
Use only insulated tools.
Connections must always be made in the sequence described in the installation section of this manual.
The installer of the product must provide a means for cable strain relief to prevent the transmission of stress to the connections.
In addition to this manual, the system operation or service manual must include a battery maintenance manual applicable to the type of batteries used. The battery must be placed in a well-ventilated area.
Warning
SELECTION OF WIRE CONDUCTORS
Use flexible multistranded copper cable for the battery and PV connections.
The maximum diameter of the individual strands is 0,4mm/0,125mm² (0.016 inch/AWG26).
A 25mm² cable, for example, should have at least 196 strands (class 5 or higher stranding according to VDE 0295, IEC 60228 and BS6360).
An AWG2 gauge cable should have at least 259/26 stranding (259 strands of AWG26)
Maximum operating temperature: ≥ 90°C
Example of suitable cable: class 5 “Tri-rated” cable (it has three approvals: American (UL), Canadian (CSA) and British (BS)).
In case of thicker strands the contact area will be too small and the resulting high contact resistance will cause severe overheating, eventually resulting in fire.
Warning
RISK OF INJURY OR DEATH
The internals can carry a 400-500V DC voltage even when the product is off!
Input and/or output terminals may still be dangerously energized, even when the equipment is switched off. Always disconnect all power connections (e.g. the battery, DC solar isolator, etc) and wait at least 5 minutes before carrying out work on the product.
The product has no internal user-serviceable components. Do not remove the front plate or operate the product if any panels have been removed. All servicing must be undertaken by qualified personnel.
Please read the installation instructions in the installation manual before installing the equipment.
This is a Safety Class I product (supplied with a protective grounding terminal). The chassis must be grounded. Whenever it is likely that the grounding protection has been damaged, the product must be turned off and secured against unintended operation; please contact qualified service staff.
Non-isolated inverters shall be provided with installation instructions that require PV modules that have an IEC 61730 Class A rating.
If the maximum AC mains operating voltage is higher than the PV array maximum system voltage, then the instructions shall require PV modules that have a maximum system voltage rating based upon the AC mains voltage.
Environment and Access
Ensure that the equipment is used under the correct ambient conditions. Never operate the product in a wet or dusty environment. Never use the product where there is a risk of gas or dust explosions. Ensure there is adequate free space for ventilation above and below the product and check that the ventilation vents are not blocked.
Ensure that the unit is installed on a non-flammable surface and that surrounding construction materials are also made of non-flammable materials.
Installation of this product must be in a location that restricts access by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
The connections to live parts should be covered after installation.
Ensure that no flammable materials or objects will be stored close to the installation after it has been commissioned.
Enclosure Symbols
Symbol on the enclosure | |
---|---|
Caution, risk of electric shock | |
Refer to the operating instructions | |
IP21 Protected from touch by fingers and objects greater than 12 millimetres. Protected from condensation. | |
European conformity | |
Regulatory compliance mark for Australia & New Zealand |
